1/ Small and light: with mid frequency transformer which is much smaller – weighing 1/5 to 1/10 while only 1/3 as big – than traditional welding power sources
2/ Efficient and energy saving: inverter welders reduce wasted power by using less copper and steel saving at least 1/3 power consumption while maintaining 80-85% efficiency with a power factor as high as 0.93.
3/ Having step-less adjustment for welding current and voltage. Different requirements for different welding techniques will be reached.
4/ Stable welding with small spatter and outstanding welding performance.
5/ With auto-compensation against power fluctuation function.
6/ Design integrated: welding anywhere and anytime, easy to operate.
|Power Voltage (V)||1 phase230V 15%|
|Rated Input Current (A)||MMA:43.6 , MIG 51.6|
|Output Current Adjustment (A)||MMA:40-200 , MIG: 40-250|
|Output Voltage Adjustment (V)||MMA:28 , MIG:26.5|
|Duty Cycle (%)||60|
|Type of Wire-feeding Speed (m/min)||Compact|
|Wire Speed (m/min)||2-15|
|Post Puff (S)||1|
|Wire Wheel Diameter (mm)||Below 200|
|Wire Diameter (mm)||0.6/0.8/1.0|
|Housing Shielding Grade||IP 21S|
|Suitable Thickness(mm)||Above 0.6|
|Dimension (mm)||468 X 245 X 478|
